SA516 Grade 70 N Boiler Pressure Vessel Steel Plates

Price:	850.0~1200.0 USD
Payment Terms:	T/T,L/C
Special Groups:	ASTM steel plates (36)
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: SA516 Grade 70 N

Production Capacity: 20000 MT/month

Delivery Date: 30 days

Means of Transport: Ocean

Packing: according to customer's req...

steel plates: SA516 Grade 70 N

SA516 Grade 70 N Boiler Pressure Vessel Steel Plates
1. Material: ASME SA516Gr 70 N, ASTM A516Gr 70 N
2.Nearest Equivalent: EN P295GH

SA516 Grade 70 N Boiler Pressure Vessel Steel Plates

1. Material: ASME SA516Gr 70 N, ASTM A516Gr 70 N

2.Nearest Equivalent: EN P295GH, DIN 17Mn4, JIS SGV480

3.Characteristic:SA516 Gr70/A516 Gr70 (N)Normalized specification covers carbon steel plates intended
for service in welded pressure vessels. It has good weldability and cold working properties.
SA516 Gr70/A516 Gr70 (N) plate is supplied in normalized or as-rolled condition.

4.Application:SA516 Gr70/A516 Gr70 (N)Normalized plate are used in Various types of pressure vessels
(containers, tanks, etc) and boiler-related industries

5.Chemical Composition(max %) of SA516 Gr70/A516 Gr70 (N)Normalized plate:
Thickness C Mn P S Si
≤ 12.5mm 0.27 1.30 0.035 0.04 0.45
12.5 - 50mm 0.28 1.30 0.035 0.04 0.45
≥ 50 - 100mm 0.30 1.30 0.035 0.04 0.45
≥ 100 - 200mm 0.31 1.30 0.035 0.04 0.45

6.Mechanical Properties of SA516 Gr70/A516 Gr70 (N)Normalized plate:
Yield Strength Tensile Strength Elongation (%)
2 in 8 in
min 260 N/mm2 485 - 620 N/mm2 min 21 min 17

7.Dimensions(T*W*L): 6--300 mm* 1500--4020mm * 3000--18000 mm

8.Adopting standard: ASTM A516/A516M , ASME SA516

9.Delivery term: Within 30 days

If you are interested in SA516 Gr 70 N Boiler Pressure Vessel Steel Plates,please contact us for more
information.
